Metcal PTTC-606/PTTC-706/PTTC-806烙铁头
Metcal PTTC-606/PTTC-706/PTTC-806烙铁头
Metcal PTTC-606/PTTC-706/PTTC-806 soldering iron tips PTTC tweezers soldering iron tips
Compatible with MX-5000 and MX-5200 systems, as well as MX-PTZ precision tweezer handle
6=600 series for temperature sensitive applications.
7=700 series for the most standard applications.
8=800 series for ceramic and high thermal energy demand applications
| Temperature series | Specifications | Lead free applications | The maximum Fahrenheit/Celsius temperature that this series can reach |
| 600 | PTTC-6XX | Temperature sensitive | 675℉/357℃ |
| 700 | PTTC-7XX | glass fibre | 775℉/412℃ |
| 800 | PTTC-8XX | ceramics | 905℉/487℃ |
This temperature is a reference temperature, and the actual temperature is not that high. The actual temperature shall prevail;
